Hualing M5 350 hp 8X4(12 wheels) 7.69 m³ concrete mixer truck (China VI)
EXW
Export quote
Hualing M5 Heavy Truck concrete mixer truck
Main model photos
436 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Hualing M5 350 hp 8X4(12 wheels) 7.69 m³ concrete mixer truck (China VI) | 8x4 / 350hp / China VI | ||
| Hualing M5 360 hp 8X4(12 wheels) 7.73 m³ concrete mixer truck (China VI) | 8x4 / 360hp / China VI | ||
| Hualing M5 360 hp 8X4(12 wheels) 7.69 m³ Concrete Mixer Truck (China VI) | 8x4 / 360hp / China VI | ||
| Hualing M5 360 hp 8X4(12 wheels) 7.69 m³ Concrete Mixer Truck (China VI) | 8x4 / 360hp / China VI | ||
| Hualing M5 360 hp 8X4(12 wheels) 7.69 m³ Concrete Mixer Truck (China VI) | 8x4 / 360hp / China VI |
Hualing M5 360 hp 8X4(12 wheels) 7.73 m³ concrete mixer truck (China VI)
EXW
Export quote
Hualing M5 360 hp 8X4(12 wheels) 7.69 m³ Concrete Mixer Truck (China VI)
EXW
Export quote
Hualing M5 360 hp 8X4(12 wheels) 7.69 m³ Concrete Mixer Truck (China VI)
EXW
Export quote
Hualing M5 360 hp 8X4(12 wheels) 7.69 m³ Concrete Mixer Truck (China VI)
EXW
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Hualing Heavy Truck 360 hp 8X4(12 wheels) concrete mixer truck (China VI) | 8x4 / 360hp / China V | ||
| Hualing Heavy Truck 360 hp 8X4(12 wheels) concrete mixer truck (China VI) | 8x4 / 360hp / China VI | ||
| Hualing Heavy Truck 345hp 6X4(10 wheels) Concrete Mixer Truck | 6x4 / 345hp / China IV | ||
| Hualing heavy truck 336hp 6X4(10 wheels) concrete mixer truck | 6x4 / 336hp / China IV | From $66,667 |
Hualing Heavy Truck 360 hp 8X4(12 wheels) concrete mixer truck (China VI)
EXW
Export quote
Hualing Heavy Truck 360 hp 8X4(12 wheels) concrete mixer truck (China VI)
EXW
Export quote
Hualing Heavy Truck 345hp 6X4(10 wheels) Concrete Mixer Truck
EXW
Export quote
Hualing heavy truck 336hp 6X4(10 wheels) concrete mixer truck
EXW
From $66,667
Export quote
Series Specs
Basic Info
Cab dimensions: 9.95×2.525×3.96 / 9.9×2.525×3.96 / 9.7×2.525×3.94 / 10.3×2.525×3.96 / 10.95×2.525×3.96 / 10.7×2.525×3.96 / 10.8×2.55×3.998 / 9.9×2.55×3.95 / 10.05×2.55×3.95 / 9.85×2.55×3.98 / 9.4×2.55×3.85 / 9.9×2.5×3.85 / 10.25×2.55×3.998 / 9.85×2.5×3.98 / 11.35×2.5×3.998 / 9×2.5×3.92 / 10.25×2.5×3.998 / 10.8×2.5×3.998 / 9.8x2.495x3.98m
Truck Type: Concrete mixer truck
Drive type: 8X4 / HN5310GJBB36C1BEV / HN5312GJBB36C5BEV / HN5314GJBB36C5BEV / HN5311GJBB36C1BEV / 6X4
Front/rear track width: Front: 2065/2065mm; Rear: 1860/1860 / 2065/2065/1860/1860 / Front: 2065mm; Rear: 1860/1860 / Front track: 2065mm; Rear track: 1860/1860 / Front track: 2065/2065mm; Rear track: 1860/1860 / Front track: 2065; Rear track: 1860/1860
Vehicle origin: Ma'anshan, Anhui
Wheelbase: 1850+3000+1350 / 1850+3100+1350 / 1850+3500+1350 / 1850+3370+1350 / 4100+1350 / 4400+1350 / 1850+3700+1350 / 3600+1350 / 1850+2700+1350mm
Curb Weight: 14.08 / 13.995 / 12.8 / 16.3 / 16.8 / 16.5 / 18.5 / 14 / 14.47 / 16.805 / 16 / 12.305 / 13.345 / 15.5 / 17.2 / 19 / 14.2 / 15ton
Rated payload: 16.79 / 16.875 / 18.07 / 14.57 / 14.07 / 14.37 / 12.37 / 16.87 / 16.4 / 14 / 16.805 / 8.805 / 18.5 / 17.46 / 15.305 / 7.67 / 11.805 / 10.605 / 7.605 / 12.305 / 8.305 / 9.805ton
Max. speed: 85 / 82 / 78km/h
Front/rear suspension: 1.37/2.38 / 1.37/2.33 / 1.37/2.13 / 1.37/2.63 / 1.37/2.88 / 1.37/2.86 / 1.37/2.48 / 1.37/3.03 / 1.37/1.83 / 1.55/2.95 / 1.37/3.08 / 1.37/2.68 / 1.37/3.13 / 1.45/3.05 / 1.37/2.98m
electric motor
Motor 1 Brand: Tebest
Motor 1 Model: TZ400XSTPG06
Motor Type: Permanent magnet synchronous motor
total rated power: 220kW
Peak power: 360kW
total peak torque: 2100N·m
total rated torque: 1500N·m
Body Parameters
Drum geometric volume: 7.7 / 4.4m³
Mixing drum capacity: 6.67 / 6.44 / 6.58 / 7.69 / 7.73 / 8 / 5.63 / 7.45 / 7.51 / 7.7 / 4 / 7 / 3.48 / 5.4 / 4.86 / 4.4m³
Drum rotation speed: 0-15r/min
Feed rate: 3.2m³/min
Discharge speed: 2m³/min
Discharge residue rate: ≤1%
Filling Rate: 23.3%
Vehicle certification code: AH5312GJBDL6 / AH5313GJB9L6 / AH5313GJB4L6 / AH5313GJB3L6 / AH5313GJB2L6 / AH5313GJBAL6 / HN5310GJBB36C1BEV / HN5312GJBB36C5BEV / HN5314GJBB36C5BEV / HN5311GJBB36C1BEV / AH5311GJB2L5 / AH5310GJB1LNG6 / AH5310GJBJL5 / AH5312GJB2L6 / AH5310GJB4L5 / AH5310GJB8L5 / AH5252GJB2L5 / AH5310GJB2L5 / AH5310GJB1L5 / AH5253GJB1L5 / AH5252GJB1L5 / AH5313GJB1L5 / AH5251GJB1L5 / AH5311GJB1L5 / AH5312GJB1L5 / AH5259GJB3L4B / AH5259GJB3
Body Brand: Hualing
Engine parameters
Engine Model: WeichaiWP8.350E61A / HanmaHM09.360 60 / Hanma CM6D28.380 50 / Hanma CM6T28.380 60 / Hanma CM6D12.360 50 / Hanma CM6D18.360 60 / WeichaiWP10.350E53 / Hanma CM6D18.345 54 / Hanma CM6D18.375 50 / Hanma CM6D18.345 50 / HualingCM6D18.310 50 / HualingCM6D18.345 40 / WeichaiWP10.336E40
Number of cylinders: 6cylinder
fuel type: Diesel / Electric / LNG (liquefied natural gas)
Displacement: 7.8 / 8.87 / 11.813 / 9.84 / 9.726L
Emission standard: China VI / China V / China IV
Max output power: 257 / 265 / 279 / 280 / 254 / 276 / 228 / 247kW
Max hp: 350 / 360 / 380 / 345 / 375 / 310 / 336Horsepower
Rated speed: 2100 / 1900rpm
Engine Type: Inline, high-pressure common rail / Electronic high-pressure common rail + SCR / High-pressure common rail / Water-cooled, four-stroke, with exhaust brake, direct injection, turbocharged intercooled
Chassis Specs
Chassis Series: HualingM5 / Hualing Heavy Truck / Hualing Star / CAMC Hanma
Chassis Model: HN1310B35CLM6J / HN1311B36CLM6J / HN1310B36C1BEVJ / HN1310B36C5BEVJ / HN1311B36C5BEVJ / HN1311B36C1BEVJ / HN1310HB38C3M5J / HN1310NGB38CLM6J / HN1310B36CLM6J / HN1310HB35CLM5J / HN1250HB35D1M5J / HN1250HB35C6M5J / HN3252B34D1M4J / HN3250B34D1M4J
Transmission Parameters
Number of gears: 9 / 12 / 8Gear
Transmission Model: Hanma9SDB1600 / Hanma9SDB2050 / 9-Speed AMT / Hanma 9-speed / Hanma12SOB2250 / Hanma12SDB2050 / Hanma9SDB2020 / Hanma8SDJ1981 / Hanma9SDB2051A / Hanma9SDB1851 / SODA 8SDC1981 / SODA 8SDB1981 / 9SDB1981
Cab parameters
Cab: Hualing Heavy Truck Flat Top
FAQ
What kind of truck is Hualing Hualing M5 Heavy Truck concrete mixer truck?
Hualing Hualing M5 Heavy Truck is an export-oriented concrete mixer truck lineup with about 38 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Hualing M5 Heavy Truck concrete mixer truck?
Hualing M5 Heavy Truck concrete mixer truck export reference is about $66,667 – $75,389. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Hualing M5 Heavy Truck concrete mixer truck cover?
Hualing M5 Heavy Truck concrete mixer truck mainly covers: Drive: 6x4 / 8x4; Horsepower: 336 hp / 345 hp / 350 hp / 360 hp; Emission: China IV / China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Hualing M5 Heavy Truck concrete mixer truck?
For Hualing M5 Heavy Truck concrete mixer truck: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is concrete mixer truck typically used for?
concrete mixer truck is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Hualing M5 Heavy Truck concrete mixer truck include?
Hualing M5 Heavy Truck concrete mixer truck currently lists about 38 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Hualing M5 Heavy Truck concrete mixer truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
